Tyrone OPSLAG D3-QFA-326D is another high-performance storage product in the OPSLAG unified block series. It is among the finest all-flash array data storage at the entry-level. Irrespective of enterprise size, its agility, and performance, ensure that even the most demanding application requirements are met successfully. It delivers excellent storage performance, enterprise-level reliability, and a flexible-to-use management system. The storage perfectly aligns with the objective of modern enterprise applications such as integrated virtualization, AI/ML, HPC, and financial services. Some of the noteworthy benefits are listed below
It is 100% native high-density flash storage. Because of this, it can deliver the performance requirements of high-performance computing infrastructure with an impeccable IOPS at µs-level latency.
The product is flexible with a high-speed 25GbE/32Gb iSCSI/Fibre Channel (FC) I/O host card. Moreover, it boasts excellent IOPs with ultra-low latency, i.e., 450Krandom write IOPs @ 500μs latency and 220K random write IOPs @ 300μs latency.
With Tyrone OPSLAG D3-QFA-326D, it is easy to upgrade and substitute system components with modular hardware design.
It has a remarkable 99.9999% high availability design without any point of failure. The cache-to-flash memory protection solution ensures that you never lose your valuable data.
You can expect a significant saving to TCO (Total Cost of Ownership) compared to industry-leading flash storage.
It will provide a perceptible SSD monitoring with cent percent accuracy of SSD utilization ratio.
| SPECIFICATIONS | |||
|---|---|---|---|
| Model Name |
D3-QFA-326D |
||
| Form Factor |
3U form factor |
||
| Raid Controller |
Supports RAID 0,1,0+1,3,5,6,30,50 & 60 with 16GB cache upgradable to 384GB
|
||
| Processor |
Six-Core Xeon Processor |
||
| Memory(Per Controller |
16GB DDR4 ECC RDIMM |
||
| Host Connectivity(per Controller) |
Host Card Slot 1 (optional): 2 x 32Gb or 4 x 16Gb or 2 x 16Gb Fibre-channel ports 2 x 25Gb (SFP28) or 4 x 10Gb (SFP+) iSCSI ports 2 x 10Gb (RJ45) iSCSI ports 4 x 1000BaseT iSCSI ports |
||
| Expansion Connectivity | Built-in 2 x 12Gb/s SAS wide ports Mix & match 3.5" & 2.5" SAS, NL-SAS, SED HDD 2.5” SAS, SATA SSD | ||
| Drive Type | Fault-tolerant and redundant modular components for SAN controller, PSU,FAN module, and dual port disk drive interface |
||
| Expansion Capabilities | Online storage pool expansion, volume extension & volume migration | ||
| Max. Drives Supported | Supports up to 26 hot-swap NVMe SSD with support of 399 TB | ||
| Dimension (HxWxD) | 438.0 x 645.0 x 132 mm (W x D x H) |
||
| Memory Protection | Battery Backup Module + Flash Module |
||
| LCM | USB LCM, Dedicated LAN port & console port for management |
||
| Power Supply | N+1 Redundant power supplies (2 x 800W, 80Plus Platinum) |
||
| SOFTWARE | |||
| Operating System | 64bit embedded Linux |
||
| Storage Management | • RAID level 0 ,1 ,0+1 ,3 ,5 ,6 ,10 ,30 ,50, 60, and N-way mirror • RAID EE level 5EE, 6EE, 50EE, and 60EE Flexible storage pool ownership • Thin Provisioning (QThin) with space reclamation • Global hot spares • Write-through and write-back cache policy • Online disk roaming • Spreading RAID disk drives across enclosures • Background I/O priority setting • Instant RAID volume availability • Fast RAID rebuild • Online storage pool expansion • Online volume extension Online volume migration1 • Auto volume rebuilding • Instant volume restoration • Online RAID level migration • SED & ISE drive support • Video editing mode for enhanced performance • Disk drive health check and S.M.A.R.T. attributes • Storage pool parity check and media scan for disk scrubbing • SSD wear lifetime indicator • Disk drive firmware batch update • QSLIfe to monitor and analyze the activity of SSDs • QSRAID for SSD endurance optimization • Multiple volume creation Volume QoS (Quality of Service) |
||
| iSCSI Host Connectivity | • Proven QSOE 2.0 optimization engine • CHAP & mutual CHAP authentication • SCSI-3 PR (Persistent Reservation for I/O fencing) support • iSNS support • VLAN (Virtual LAN) support • Jumbo frame (9,000 bytes) support • Up to 256 iSCSI targets • Up to 512 hosts per controller • Up to 1,024 sessions per controller |
||
| Fibre Channel Host Connectivity | • Proven QSOE 2.0 optimization engine • FCP-2 & FCP-3 support • Auto detect link speed and topology • Topology supports point-to-point2 and loop • Up to 256 hosts per controller |
||
| High Availability | • Dual-Active (Active/Active) SAN controllers • Cache mirroring through NTB bus • ALUA support • Management port seamless failover • Fault-tolerant and redundant modular components for SAN controller, PSU, FAN module, and dual port disk drive interface • Multipath I/O and load balancing support (MPIO, MC/S, Trunking, and LACP) • Firmware update with zero system downtime |
||
| Storage Effciency | • Thin Provisioning (QThin) with space reclamation |
||
| Networking | • DHCP, Static IP, NTP, Trunking, LACP, VLAN, Jumbo frame (up to 9,000 bytes) |
||
| Advanced Data Protection | • Snapshot (QSnap), block-level, differential backup • Writeable snapshot support • Manual or schedule tasks • Up to 64 snapshots per volume • Up to 64 volumes for snapshot • Up to 4,096 snapshots per system • Snapshot recycle bin • Remote Replication (QReplica) • Auto remote replication without doing configurations • 1 Step Local-to-Remote • Asynchronous, block-level, differential backup based on snapshot technology • Traffic shaping for dynamic bandwidth controller • Manual or schedule tasks • Synchronous, block-level, always synchronize based on the recorded fracture log • Traffic shaping for dynamic bandwidth controller • Manual or schedule tasks • Volume clone for local replication • Auto local clone without doing configurations • Configurable N-way mirroring • Integration with Windows VSS (Volume Shadow Copy Service) Instant volume restoration Cache-to-Flash memory protection M.2 flash module Power module: BBM (Battery Backup Module) Support USB UPS and network UPS with SNMP management |
||
| Virtualization Certifcation | • Server Virtualization & Clustering • Latest VMware vSphere certification • VMware VAAI for iSCSI &, FC Windows Server 2016, 2012 R2 Hyper-V certification Microsoft ODX Latest Citrix XenServer certification |
||
| Easy Management | • USB LCM3, serial console support, online firmware update • Intuitive Web management UI, secured web (HTTPS), SSH (Secured Shell), LED indicators • S.E.S. support, S.M.A.R.T. support, Wake-on-LAN, and Wake-on-SAS • Grouping batch operation for host and protection groups • QReport generates performance and capacity analytics • XFinder utility support to easy find storage system RESTful API support QAuth for authorizations of user’s responsibility |
||
| Host Operating Systems Support | • Windows Server 2008, 2008 R2, 2012, 2012 R2, 2016, 2019 • SLES 10, 11, 12, 15 • RHEL 5, 6, 7, 8 • CentOS 6, 7, 8 • Solaris 10, 11 • FreeBSD 9, 10, 11, 12 • Mac OS X 10.11 or later |
||
