Supports Dual Intel® Xeon® 6th Gen 6500/6700 processors
•
Supports 8+8 DDR5 RDIMM Expandable Memory
•
6 x16 PCIe 5.0 Expansion Slots
•
Latest AST2600 BMC Controller iKVM, vMedia support
•
Support 8 x 3.5"/2.5" Hot Swappable Bays
•
Dual 1GbE(RJ45) by Broadcom BCM5720
•
Multiple PSU Options 800W/1300W/1600W 80+ CRPS
Processor/Cache
Processor
Supports Dual Intel Xeon 6th Gen 6500/6700 Series CPUs of TDP upto 350W (FCLGA 4710)
System Memory
Memory Capacity
Supports 8+8 DDR5 RDIMM Expandable Memory, Max Frequency 6400MHz Max Capacity 64GB/DIMM, Max System Memory 1TB
Expansion Slots
PCI-Express
6 x16 PCIe5.0 / CXL2.0
Ports
Ports
1 x RJ45 (RTL8211E) GbE connector for BMC dedicate management port (Rear) 2 x 1GbE (RJ45) by Broadcom BCM5720 (Rear) 2 x USB 3.0 Type A Ports (Front) 2 x USB 3.0 Type A Ports (Rear) 1 x DB-15 VGA connector (Rear) 1 x External UID/switch button (Rear)
Front LEDs
Front LEDs
1 x Power LED Button 1 x Alert LED 1 x HDD Activity 2 x LAN Activity 1 x Reset Button 1x UID LED Button
Drive bays
Drive bays
Supports 8 x (SAS/SATA) 2.5"/3.5"Hot Swappable Bays 2 x M.2 2280 PCIe 5.0 x4 (Onboard) 2 x 2.5" SATA Internal Drives 1 x Slim DVD-ROM
Security
Security
Chassis intrusion TPM 2.0
Power Supply
Power Supply
800W/1300W/1600W 80+ CRPS
Form Factor
Form Factor
2U Rackmount
Dimensions
Dimensions: 680 x 430 x 88 mm
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
