Supports Intel® Xeon® 6th Gen 6700P/6700E-series processors
•
NVIDIA HGX B300 8-GPU with NVSwitch
•
8 x OSFP 800 Gbps Infiniband Ports
•
Supports 16+16 DDR5 RDIMM Expandable Memory
•
4 x16 PCIe 5.0 Expansion Slots
•
Latest AST2600 BMC Controller iKVM, vMedia support
•
Support 8 x Gen5.0 x4 E1.S Hot Swappable Bays
•
Dedicated Management Port
•
Dedicated Network Port for PXE
•
(6 + 6) 3200W 80+ Redundant Titanium Power Supply
Processor/Cache
Processor
Supports Dual Intel® Xeon® 6th Gen 6700P/6700E series Processors of upto 350W TDP (LGA 4710)
System Memory
Memory Capacity
Supports 16+16 DDR5 RDIMM Expandable Memory Max Up to 6400 MT/s Max Capacity : 256GB/DIMM, Max System Memory 8TB
Expansion Slots
PCI-Express
4 x PCIe5.0 x16 FHFL Slots
Drive bays
Drive bays
Supports 8 x PCIe Gen5.0 x4 E1.S NVMe Hot Swappable drive Bays Supports 2 x M.2 2280 Internal Drives
I/O Ports
I/O Ports
8 x 800G OSFP port through integrated NVIDIA ConnectX®-8 SuperNICs (Front) 1 x 1GbE RJ45 I210 Lan port (Front) 1x 1GbE RJ45 dedicated management port (Front) 1 x Mini DP Port (Front) 1 x USB 3.0 Type A (Front)
LEDs / Buttons
LEDs / Buttons
1 x Power button/LED (Front) 1 x Reset button (Front) 1 x UID button/LED (Front) 1 x UART Debug Port
Power Supply
Power Supply
(6 + 6) 3200W 80+ Redundant Titanium Power Supply
Security
Security
TPM 2.0
Form Factor
Form Factor
10U Rackmount
Dimensions
447mm (W)x 800mm (D)x 442mm(H)
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
