• Cloud Backup, Data Replication, or High Density Archive Storage Applications
• 2U Storage JBOD Chassis with capacity 12 x 3.5" hot-swappable HDDs bays
• Dual Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput
• 8 x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements
• 1x IPMI port for Remote System Power on/off and system monitoring
• Support NTP for time synchronization & RTC battery backup
• 600W / 650W/ 740W Redundant Power Supply
• 3 x 80mm high efficient hot-swappable fans for best system cooling
• Ideal for Cloud backup, data Replication or High desnsity Archive Storage Applications

Backplane
Backplane
12-port 2U SAS3 12Gbps dual-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD
Front Panel
LED Indicators 1 Network Activity LEDs
Buttons Power On/Off button, System Reset Button, Unit Identification (UID) button
Drive bays
HDD bays 12 x 3.5" hot-swap drive bay
Power Supply
Power Supply 600W / 650W/ 740W Redundant Power Supply
Cooling System
Cooling System 3 x 80x38mm hot-swap cooling fan(s)
Form Factor
Form Factor 2U JBOD storage chassis
Height 3.5" (89 mm),Width 17.2" (437 mm),Depth 25.5" (647 mm)

Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
