A high-performance single-socket AMD EPYC™ 9004/9005 platform optimized for PCIe Gen5 I/O, dual OCP 3.0 networking, high-density DDR5 memory, NVMe storage, and enterprise-grade security with hardware Root of Trust.
•
Support Single AMD EPYC™ 9004/9005 Series processor with high-core-count architecture
•
Supports 24 x DDR5 RDIMM Expandable Memory
•
2 x PCIe Expansion Slots
•
2 x PCIe 5.0 x16 OCP3 NIC Mezzanine slot
•
Integrated ASPEED BMC Controller
•
Dual BIOS & BMC
•
Supports IPMI, Redfish, remote KVM, and virtual media
•
80+ Titanium CRPS Power Supply for high efficiency and redundancy
•
Enhanced Security with TPM 2.0 and Chassis Intrusion detection
•
Hardware Root of Trust (RoT)
•
Supports 2 x 400W Passive GPU
Processor/Cache
Processor
Support Single AMD EPYC™ 9004 and 9005 series processor,Upto 500W TDP, (LGA 6096)
System Memory
Memory Capacity
24 x DDR5 DIMM Slots, 12 channels(2DPC), RDIMM/RIMM-3DS Max. Frequency 5200MT/s(1DPC), 4400MT/s(2DPC)* *Subject to CPU & Memory Configuration. Max. Capacity per DIMM: 256GB Max System Memory : 6TB
Expansion Slots
PCI-Express
2 x PCIe 5.0 x16 FHFL dual wide slot 2 x PCIe 5.0 x16 OCP 3.0 slot
Drive bays
Drive bays
8 x 2.5" U.2 PCIe 5.0 x4 Hot Swap NVMe drive bays 2 x 2280/22110 PCIe 3.0 x2 NVMe M.2 drive bays
Ports
Ports
1 x 1000Base-T Dedicated Server Management Port (Rear) 2 x USB 3.0 Type-A Port (Front) 1 x Mini-DP Display Port (Rear) 1 x COM USB Type A Port (Rear) 1 x USB 2.0 Type-A Port (Rear)
Indicators/LEDs
Indicators/LEDs
1 x Power button with LED (Rear/Front) 1 x UID button with LED (Rear/Front) 1 x Reset Button (Front) 4 x Status LEDs : LAN/M.2/Fault(Front/Rear)
Security
Security
Chassis intrusion TPM 2.0 (Optional) Hardware Root of Trust (RoT)
Power Supply
Power Supply
(1+1) 2400W 80+ CRPS Titanium Redundant Power Supply
Non-operating Relative Humidity: 5% to 85% (non-condensing)
Form Factor
Form Factor
2U Rackmount
Dimensions
438mm (W) x 87mm (H) x 764mm (D)
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
