Supports 16+16 DDR5 Expandable Memory, Max Frequency (with 6400MT/s rated): : RDIMM : 5200MHz(1R/2R)(1DPC), 4400 MT/s (1R) or 4000 MT/s (2R) (2DPC) Max. Capacity per DIMM: 128GB(RDIMM), Upto 4TB System Memory
Expansion Slots
PCI-Express
8 x PCIe5.0 x16 FHFL (Double Width), CXL® 2.0 5 x PCIe5.0 x16 FHFL (Single Width)* *(Recommended Config : 1 x NVIDIA BlueField®-3 DPU & 4 x NVIDIA ConnectX®-7 NICs)
Drive bays
Drive bays
8 x E1.S NVMe Hot-swappable 2 x M.2 2280/22110 PCIe 5.0 x4
Ports
Ports
1 x 1000Base-T Dedicated Server Management Port (Front) 1 x USB 3.0 Type-A Port (Front) 1 x Mini-DP Display Port (Front) 1 x Micro USB port (BMC Debug Console)
Indicators
Indicators
1 x Power button with LED (Front/Rear) 1 x UID button with LED (Front/Rear) 1 x System status LED (Rear) 1 x BMC reset button (Front/Rear) 1 x E1.S hard drive status LED (Front) 1 x Power supply unit status LED (Rear)
Security
Security
TPM 2.0
Power Supply
Power Supply
2700W (3+1) 80+ CRPS Titanium Certified
Environment
Environment
System Operating Temperature: 0°C ~ 35°C Non-operating Temperature: -20°C ~ 70°C Non-operating Relative Humidity: 5% to 85% (non-condensing)
Form Factor
Form Factor
4U Rackmount
Dimensions
438mm(W) x 176mm(H) x 800mm(D)
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
