Powering the AI Industrial Revolution with 64 NVIDIA HGX™ B300 GPUs in a high-density, liquid-cooled rack-scale platform.
•
High-density AI rack integrating HGX™ B300 based servers with 64 x B300 NVIDIA GPUs in rack
•
Massive HBM3e memory enabling large-scale AI training and inference
•
Powerful host computing with Dual Intel® Xeon® 6th Gen processors per server
•
Ultra-fast networking through 800Gb/s NVIDIA ConnectX®-8 SuperNIC™ interfaces
•
Infrastructure acceleration and security with NVIDIA BlueField®-3 DPUs
•
Advanced thermal efficiency enabled by direct liquid-cooling architecture
•
High-speed storage with PCIe Gen5 NVMe drives for data-intensive workloads
•
Fully integrated 48U turnkey AI platform engineered for rapid deployment at scale
•
Robust remote monitoring and management via ASPEED AST2600 BMC with IPMI 2.0
•
Enterprise-grade security backed by TPM 2.0 trusted platform technology
•
Designed to power next-generation AI factories, LLM training, and inference clusters
Processor/Cache
Processor
Dual Intel® Xeon® 6th Gen 6700 Series processors Socket LGA 4710 (E2), up to 350W TDP Chipset: System on Chip (SoC)
System Memory
Memory Capacity
CPU Memory: 32 x DDR5 DIMM slots Max. Capacity: 64 GB per DIMM Max. DIMM Frequency: 6400MT/s (1DPC) and 5200MT/s (2DPC) Max. System Memory: 2 TB
GPU
GPU
8 x NVIDIA HGXTM B300 GPUs GPU Memory: 2.3 TB HBM3e Memory Total Bandwidth: 64 TB/s
NIC
NIC
8 x Integrated NVIDIA ConnectX®-8 SuperNICTM ports (800Gb/s) 2 x i350 1GbE Ports
Drive bays
Drive bays
8 x 2.5" PCIe 5.0 x4 NVMe U.2 drives (Front) 2 x 2.5" PCIe 5.0 x4 NVMe U.2 OS drives (Front)
Display
Display
1 x DB-15 VGA Port
Management
Management
1 x Dedicated RJ45 management port for IPMI / BMC (Per Server) IPMI 2.0 (ASPEED® AST2600)
Security
Security
TPM 2.0
Expansion Slot
Expansion Slot
2 x FHHL PCIe5.0 x16 Slots
Ports
Ports
8 x NVIDIA ConnectX®-8 SuperNICTM1 x IPMI RJ45 Port (Rear, shared with Front) 2 x 1GbE RJ45 Port (Rear, shared with Front) 2 x USB 3.0 Port (Front) 1 x Micro USB for debug Port (Front) 1 x VGA DB-15 Port (Front) 2 x USB 3.0 Port (Rear)
Indicators
Indicators
1 x Power Button (Front/Rear) 1 x UID Button (Front/Rear) 1 x Reset Button (Front) 1 x NMI Button (Front)
Cooling System
Cooling System
Cooling Architecture: Liquid Cooled
Power Supply
Power Supply
(5+5) Redundant 3000W 80 PLUS Titanium CRPS Power Supply
Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 8% to 90% (non-condensing)
Form Factor
Form Factor
48U Rack
Dimensions
Product Dimensions : 800mm (W) x 2306.5mm (H) x 1500mm (D) Packing Dimensions : 1220mm (W) x 2500mm (H) x 1680mm (D) Net Weight: 1638 Kg | Gross Weight: 1930 Kg
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
