Ultra-dense liquid-cooled AI platform powered by dual NVIDIA® GB200 Grace Blackwell Superchips with NVLink™ interconnect and 800Gb/s networking delivering exceptional AI performance.
Latest AST2600 BMC Controller iKVM, vMedia support
•
80+ Titanium CRPS Power Supply with N+1 redundancy.
•
Built-in Hardware security(TPM 2.0)
•
Cryptographically signed firmware using CEC1736 EROT
Superchip
Superchip
2 x liquid-cooled NVIDIA GB200 Grace Blackwell Superchips Per superchip: 1 x NVIDIA Grace™ CPU 2 x NVIDIA Blackwell GPUs CPU and GPU connected with NVIDIA NVLink™-C2C GPU and GPU connected with NVIDIA NVLink™ GPU TDP up to 1200W
System Memory
Memory Capacity
NVIDIA Grace™ CPU: 480GB of LPDDR5X memory with ECC Memory bandwidth up to 512GB/s NVIDIA Blackwell GPU: 186GB HBM3E Memory bandwidth up to 8TB/s
NIC
NIC
4 x 800 Gb/s liquid-cooled OSFP InfiniBand XDR for GPU networking, via NVIDIA ConnectX®-8 SuperNIC™ 1 x 1Gb/s LAN (1 x Intel® I210-AT) 1x 10/100/1000 Mbps Management LAN
Drive bays
Drive bays
Front: 8 x Air-cooled E1.S PCIe Gen5.0 NVMe Internal M.2: 1 x M.2 (2280/22110), PCIe Gen5.0 x4
Display
Display
Integrated in ASPEED® AST2600 1 x Mini-DP
Security
Security
RoT : CEC1736 EROT ,Dual ROM. TPM : SLB 9672 FW15
Expansion Slot
Expansion Slot
1 x FHHL x16 (Gen5) for DPU(Recommended Configuration)
Ports
Ports
1 x USB 3.2 Type-A Gen1 Port (Front) 1 x Micro USB port (Front) 1 x Mini-DP Port (Front) 1 x RJ45 Dedicated Management Port (Front) 1 x RJ45 Network LAN Port (Front)
Indicators/LEDs
Indicators/LEDs
1 x Power button with LED (Front) 1 x ID button with LED (Front) 8 x Storage activity LEDs (Front) 1 x NVLink status LED. (Front) 1 x BMC reset button (Front) 4 x Power Supply Status LED (Rear)
Environment
Temperature
Operating temperature: 10°C to 35°C Operating humidity: 8% to 80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20% to 95% (non-condensing)
Power Supply
Power Supply
(3+1) Redundant 80 Plus 2700W Titanium CRPS Power Supply
Form Factor
Form Factor
2U Rackmount
Dimensions (W x H x D )
448mm (W) x 87mm (H) x 768mm (D)
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
