Supports AMD Dual EPYC 9005/9004 series processors
•
NVIDIA HGX B300 8-GPU with NVSwitch
•
8 x OSFP 800 Gbps Infiniband Ports
•
Supports 12+12 DDR5 RDIMM Expandable Memory
•
4 x16 PCIe 5.0 Expansion Slots
•
Latest AST2600 BMC Controller iKVM, vMedia support
•
Support 12 x 2.5" Hot Swappable Bays
•
Dual 1GbE(RJ45) via Intel i350-AM2
•
(6 + 6) 3000W 80+ Redundant Titanium Power Supply
Processor/Cache
Processor
Supports Dual Supports AMD EPYC 9005/9004 series Processors of upto 500W TDP (LGA 6096)
System Memory
Memory Capacity
Supports 12+12 DDR5 RDIMM Expandable Memory Max Supported Frequency : 6400 MT/s (Depends Upon CPU SKU) Max Capacity RDIMM : 128GB/DIMM
Expansion Slots
PCI-Express
4 x16 PCIe 5.0 FHHL single width slots
Drive bays
Drive bays
Supports 12 x 2.5" NVMe Hot Swappable drive Bays Supports 2 x M.2 PCIe x4 Internal Drives
I/O Ports
I/O Ports
2 x RJ45 1G Base-T via Intel i350-AM2 (Front) *Same can be accessible from Rear Side as well 1 x RJ45 dedicated IPMI 2.0 LAN port (Front) *Same can be accessible from Rear Side as well 1 x VGA DB15 Port (Front) 4 x USB 3.0 Type A (Front) 2 x USB 3.0 Type A (Rear) 1 x VGA DB15 Port (Rear)
LEDs / Buttons
LEDs / Buttons
1 x Power button/LED (Front) 1 x Reset button (Front) 1 x UID button (Front/Rear) 1 x System Fault LED (Front) 12 x HDD LEDs (Front)
Security
Security
TPM 2.0
Power Supply
Power Supply
(6 + 6) 3000W 80+ Redundant Titanium Power Supply
Form Factor
Form Factor
8U Rackmount
Dimensions
Dimensions: 448mm x 930mm x 354mm
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
