Supports 16+16 DDR5 RDIMM Expandable Memory Max 5600 MT/s (1DPC) / 4400 MT/s (2DPC) Frequency (Depends Upon CPU SKU) Max Capacity RDIMM-3DS : 256GB/DIMM, Max System Memory 8TB
Expansion Slots
PCI-Express
8 x16 PCIe 5.0 HHHL single width slots 2 x16 PCIe 5.0 FHHL single width slots
Drive bays
Drive bays
Supports 10 x 2.5" NVMe Hot Swappable drive Bays Supports 2 x 2.5" SATA Hot Swappable drive Bays Supports 2 x M.2 PCIe x4 Internal Drives
I/O Ports
I/O Ports
2 x RJ45 1G Base-T via Intel i350-AM2 (Front) *Same can be accessible from Rear Side as well 1 x RJ45 dedicated IPMI 2.0 LAN port (Front) *Same can be accessible from Rear Side as well 1 x VGA DB15 Port (Front/Rear) 4 x USB 3.2 Type A Gen1 (Front) 2 x USB 3.2 Type A Gen1 (Rear)
LEDs/Buttons
LEDs/Buttons
1 x Power button/LED (Front) 1 x Reset button (Front) 1 x UID button (Front/Rear) 1 x System Fault LED (Front) 12 x HDD LEDs (Front)
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
