Applications - Virtualization, Software-defined Storage, Cloud Computing, Enterprise Server
•
Dual Socket E (LGA-4677), Intel® Xeon® 5th Gen / 4th Gen, Intel Xeon CPU Max Series with HBM CPU TDP Support Upto 300W with air cooling, Support HBM and CXL
•
Intel® C741 Chipset, Aspeed 2600 series BMC (1920 x 1200 , 16MB Memory)
•
1 x OCP 3.0, 2 x NVMe M.2, 1 x VGA, 2 x USB 3.0, 2 x USB 3.0 (Optional), 1 x Serial Port (Optional)
•
Configuration Options for up to 4 PCI-E 5.0 x16 Slots OR up to 6 PCI-E 5.0 x8 Slots
•
4U Rackmount Chassis, 60 x 3.5" Top Loading Bays (SAS/SATA) with expander backplane 12 x 2.5”/3.5" Rear Bays (SAS/SATA/NVMe) with direct attached backplane
•
Redundant & Hot-Swappable 80+ Titanium Power Supply (2000W / 2400W) PMBus 1.2 Support for Remote Management
•
SLB 9672 chipset based TPM 2.0 Module
Processor/Cache
Processor
Dual Socket E (LGA-4677), 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors Supports Intel Xeon CPU Max Series with high bandwidth memory (HBM) Note : Supports up to 300W TDP CPUs (Air Cooled),
Core Count
Upto 64C/128T; Upto 320 MB Cache Per CPU
System Memory
Memory Capacity
Slot Count: 32 DIMM slots, Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM Max Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMM)
Onboard devices
Chipset / BMC
Intel® C741 Chipset, Aspeed 2600 series BMC
Network
1 x OCP 3.0 for Flexible networking, WOL, PXE support, BMC LAN supports DHCP, IPV4, IPV6
IPMI
IPMI 2,0 iKVM, Virtual Media Redirection, IPMI over LAN, Serial over LAN, SMASH-CLP Support, Built-in HTML5 GUI, SNMP v2/v3, 1 RJ45 Dedicated BMC LAN port for Remote Management LAN & WAN with SSL encryption,
USB / Serial
2 x USB 2.0, 2 x USB 3.0 (Optional), 1 x Serial Port (Optional)
Graphics
Aspeed 2600 series BMC (1920 x 1200 , 16MB Memory, 1 x VGA Port)
Expansion Slots
PCI-Express
Upto 4 x PCIe 5.0 x16 or upto 6 x PCIe 5.0 x8 Supports upto 4 x Network Cards (x4, x8, x16) or Video Cards, Supports upto 4 x Storage Cards
Chassis and Drive Bays
Form Factor
4U rackmount
Dimensions
1046.4*446.2*175.7 (D x W x H) (D=1191 with CMA)
Power Supply
Redundant & Hot-Swappable 80+ Titanium Power Supply (2000W/2400W)
Fans
Heavy duty fans with optimal fan speed control (Redundant, Hot-Swappable),
Drive bays
60 x 3.5" Top Loading Bays (SAS/SATA) with expander backplane 12 x 2.5”/3.5" Rear Bays (SAS/SATA/NVMe) with direct attached backplane Default support for 8 x SATA3 rear drive bays and 2 x M.2 NVMe Upto 72 x SAS3 / SATA3 or 12 NVMe via Optional Storage Controllers, Support for Broadcom MegaRAID and Adaptec® Controllers
Features
Hardware Monitoring
LED indicators for Power status, System alert, LAN activity, Drive activity, System ID, Monitoring & Management for CPU, GPU, Memory, Storage, Network and Chassis Environment for power and cooling. Actual or Impending failure alerts using event logs and SMART attributes, Monitoring of CPU voltages, Chipset Voltage, PSU +5V standby, +5V, +3.3V, +12V
BIOS Features
ACPI 6.4, SMBIOS 2.8/3.5, UEFI 2.8A, Plug and Play (PnP), PCI 5.0, USB 3.0, NVMe 2.0c
Management and Security
Management
Monitoring, Event Handling and Alerting, System Fault, Health Management and diagnosis with event logs repository, Telemetry Streaming with inventory export, Remote Power Management (on/off), Protocols (Redfish API, LDAP, NTP, HTTPS, AD 1.0, SMTP, RSYSLOG, SNMP v2, v3 etc.), TLS 1.2, Updating Firmware , BIOS, Drivers using BMC WEB GUI, Additional Licenses for respective features for System Management using different interfaces such as Web/CLI/Redfish API. Optional – SIE (Sanitize Instant Erase), SED (Self-Encrypting Drive) (with supported Controllers and featured disks), Storage Management Utility featuring creation and destroying RAID Configurations for virtual disks, Tyrone ProServe suit support for centralized management
Security
Password protection, UEFI Secure BIOS/Firmware (BIOS and NIC level Boot), Intel® TXT, Dual SRoT (TPM & PRoT), Platform Firmware Resiliency (NIST SP 800-193), OOB Server Intrusion Detection, System Lockdown, USB dynamic enable/disable (optional), Secure firmware updates, Policy defined security measures, RBAC, Configuration backup and restore, Encryption protocols – DES, AES, BIOS / Firmware Protection (NIST SP 800-147b) – Secure flash, Automatic & Secure Recovery & Anti-rollback, Tyrone Secure Platform, Access Control List
OS and Virtualization Compliance and Support
OS and Virtualization Compliance and Support
Windows Server 2019, 2022 x64, RHEL 8.5, 9.0 x64, Oracle 8.5, 9.0 x64, Rocky 8.5 x64, SLES 15 x64, Ubuntu Linux 22.04 Windows Hyper-V, Red Hat OpenShift Container Platform 4.13, Red Hat OpenStack Platform 17.0, VMware ESXi 7.0, 8.0, Citrix Hypervisor 8.2
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
